機組參數(shù) Unit parameters | ||||||||||||
機組型號 | 額定功率 | 額定 電流 | 額定 電壓 | 額定 頻率 | 電機容量 | 柴油 機型號 | 額定轉(zhuǎn)速 | 機油容量 | 冷卻液容量 | 滿載燃油消耗量 | 外形尺寸 | 重量 |
Unit model | Rated power | Rated current (A) | Rated voltage (V) | Rated frequency (Hz) | Motor capacity (KVA) | Engine model | Rated speed (r/min) | Lubr-oil capacity | Coolant capacity (L) | Fuel consumption at full load(L/h) | Dimensions (mm) | Weight (kg) |
LC20KW | 20 | 36 | 400/230 | 50/60 | 24 | 2110 |
| 10 | 15 | 6.1 | 1550*600*1150 | 450 |
LC30KW | 30 | 54 | 37.5 | K4100D | 1500/1800 | 12 | 17 | 7.1 | 1700*600*1150 | 600 | ||
LC40KW | 40 | 72 | 50 | K4100ZD | 12 | 17 | 11.6 | 1800*600*1150 | 700 | |||
LC50KW | 50 | 90 | 62.5 | ZH4105ZD | 14 | 25 | 13.3 | 1800*720*1250 | 850 | |||
LC75KW | 75 | 135 | 93.75 | R6105ZD | 16 | 29 | 19.9 | 2200*720*1500 | 1200 | |||
LC100KW | 100 | 180 | 125 | R6105AZLD | 16 | 29 | 25.1 | 2300*720*1500 | 1200 | |||
LC120KW | 120 | 216 | 150 | R6105IZLD | 16 | 29 | 30.1 | 2300*720*1500 | 1200 | |||
LC150KW | 150 | 270 | 187.5 | 6110ZLD | 16 | 29 | 37 | 2400*906*1650 | 1300 | |||
LC150KW | 150 | 270 | 187.5 | 6113AZLD | 16 | 29 | 39.3 | 2400*906*1650 | 1400 | |||
LC200KW | 200 | 360 | 250 | 6126ZLD | 20 | 70 | 47.8 | 2800*.946*1750 | 1500 | |||
LC250KW | 250 | 450 | 312.5 | 6126AZLD | 20 | 70 | 53.8 | 2800*946*1750 | 1700 | |||
LC300KW | 300 | 540 | 375 | 6126IZLD | 20 | 70 | 71.7 | 3000*1000*1750 | 2300 | |||
LC400KW | 400 | 720 |
|
| 500 | WP12 |
| 80 | 80 | 72 | 3200*1000*1750 | 2700 |
